1858772

Phoenix Contact COMBICON GMSTB 系列 7.62mm 节距 3 路 母 绿色 印刷电路板连接器 1858772, 螺钉端接

Conn Terminal Block F 3 POS 7.62mm Screw RA Panel Mount 12A

欧时:
GMSTB 2,5/ 3-STF-7,62

得捷:
TERM BLOCK PLUG 3POS STR 7.62MM

艾睿:
Ideal for testing purposes this 1858772 PCB terminal block manufactured from Phoenix Contact will exceed your needs. This F connector has 3 contacts that are plated with tin. This is a 1-row connector. It has a right angle body orientation. Its pitch is 7.62 mm. It has a female type gender. It has a maximum voltage rating of 630 V. 1858772 is housed in polyamide. This device has a maximum current rating of 12 A. This product is 33.25 mm long, 15 mm tall and 18.2 mm deep. Its wire is 12-24 AWG. It uses the screw termination method.

Verical:
Conn Terminal Block F 3 POS 7.62mm Screw RA Panel Mount 12A

MASTER:
PCB connector - nominal current: 12 A - rated voltage III/2: 630 V - nominal cross section: 2.5 mm² - number of positions: 3 - pitch: 7.62 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin

Online Components:
Conn Terminal Block F 3 POS 7.62mm Screw RA Panel Mount 12A

Electro Sonic:
PCB connector - nominal current: 12 A - rated voltage III/2: 630 V - nominal cross section: 2.5 mm² - ...
