TSW-117-05-G-D

SAMTEC TSW-117-05-G-D Board-To-Board Connector, 2.54mm, 34Contacts, Header, TSW Series, Through Hole, 2Rows

针座 通孔 34 位置 0.100"（2.54mm）

得捷:
CONN HEADER VERT 34POS 2.54MM

艾睿:
Use this unshrouded TSW-117-05-G-D header connector from Samtec where IDC ribbon cables are used. This HDR connector&s;s 34 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a header type gender. Its pitch is 2.54 mm. This is a 2-row connector. It has a maximum voltage rating of 550 VAC. It has a straight body orientation. This device has a maximum current rating of 6.3 A/contact. This product comes packaged in bulk, so the parts will be stored loosely. TSW-117-05-G-D is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. This product is 43.18 mm long, 5.21 mm tall and 5.08 mm deep. It uses the solder termination method.

Newark:
# SAMTEC  TSW-117-05-G-D  Board-To-Board Connector, 2.54 mm, 34 Contacts, Header, TSW Series, Through Hole, 2 Rows
