ERJ6BQFR91V

0805 格式低电阻电阻器 - 0.25WPanasonic ERJ 6B 厚膜芯片电阻器轻便紧凑。 这些电阻器由三层电极、金属釉厚膜电阻元件构成，非常可靠。符合 AEC-Q200 电流感应 小尺寸 低电阻值 适用于流动焊接和回流焊接 ### 应用这些电流感应电阻器符合 AEC-Q200 标准，可在汽车应用中使用。 ### 标准IEC 60115-8, JIS C 5201-8, JEITA RC-2144### 厚膜 - 0805### 应用包括：电信设备 收音机和录音机，TV 调谐器 摄像机，表，袖珍计算器 汽车工业 计算机，仪器

The ERJ 6B series resistors are automotive grade, high power current sensing chip resistors with low resistance values. The resistance range includes E24 decade values from 5mohm to 9.1ohm. ERJ series resistors have metal glaze thick film resistive element and three layers of electrodes that make them highly reliable.

.

EIA 0402, 0603, 0805, 1206, 1210, 1812, 2010, 2512 case sizes available

.

Small size, low weight resistors

.

Automotive grade AEC-Q200 compliant

.

Maximum power rating of 1W

.

Available in ±1%, ±2% and ±5% tolerance

.

0 to 300, 0 to 500, 0 to 700, ±75, ±100, ±150, ±200, ±250, ±300ppm/°C TCR values available

.

Operating temperature range -55°C to 125°C

.

Meets IEC 60115-8, JIS C 5201-8, JEITA RC-2144 standards

.

Suitable for both reflow and flow soldering
