FS215R04A1E3DBOMA1

40V Single N-Channel HEXFET Power MOSFET in a TO-220AB package

Summary of Features:

.

Complete 3-phase Six-Pack with NTC in one compact module

.

High efficient 400Vces Ultra Thin Wafer Trench-Field-Stop IGBT3 with matching 400V Emitter Controlled 3 diode.

.

Increased diode current capability optimized for generator mode in hybrid electric vehicles

.

25% reduced gate charge compared to IGBT3 650V reduces gate driver power losses

.

Enhanced wire bonding

.

Rugged Al 2O 3 ceramic for automotive applications with high thermal cycle requirements

.

Copper base plate for optimized cooling

Benefits:

.

High efficient system approach for DCL voltages up to 200V

.

High reliability

.

Same mounting as HybridPACK1 modules with 650V chipset modular approach
