RPR20-2415S

Recom POWERLINE+ 20W PCB Mount Railway DC/DC Converter - RPR20 SeriesPOWERLINE+ 20W RPR20 series PCB mount railway DC/DC converters with single and dual outputs for use in railway stock applications. These RPR series 20W railway DC/DC converters feature ICE technology Innovation in Converter Excellence which works to minimise the internal power dissipation and increase the internal temperature limits and ambient operating temperature range to the maximum. This results in these railway DC/DC converters having a wide operating temperature of -45 to +85°C without derating. These railway DC/DC converters also feature a built in EMI filter and a compact, ribbed aluminium case with a built-in heatsink.ICE technology Wide range of input voltages 85°C maximum operating temperature without derating Six sided shielded enclosure Ribbed case with built-in heatsink Efficiency of up to 89% Isolated and fully protected outputs Overload, short circuit and output over voltage protection Low quiescent current EMC compliance to EN50121-3-2 ### 注MTBF: BELLCORE TR-NWT-000332 Case l: 50% Stress, Temperature at 50°C Ground Benign### 标准Certified to EN-60950-1, 1st Edition### Recom 20W 至 60W

Recom POWERLINE+ 20W PCB Mount Railway DC/DC Converter - RPR20 Series

POWERLINE+ 20W RPR20 series PCB mount railway DC/DC converters with single and dual outputs for use in railway stock applications. These RPR series 20W railway DC/DC converters feature ICE technology Innovation in Converter Excellence which works to minimise the internal power dissipation and increase the internal temperature limits and ambient operating temperature range to the maximum. This results in these railway DC/DC converters having a wide operating temperature of -45 to +85°C without derating. These railway DC/DC converters also feature a built in EMI filter and a compact, ribbed aluminium case with a built-in heatsink.

ICE technology

Wide range of input voltages

85°C maximum operating temperature without derating

Six sided shielded enclosure

Ribbed case with built-in heatsink

Efficiency of up to 89%

Isolated and fully protected outputs

Overload, short circuit and output over voltage protection

Low quiescent current

EMC compliance to EN50121-3-2

### 注

MTBF: BELLCORE TR-NWT-000332 Case l: 50% Stress, Temperature at 50°C Ground Benign

### 标准

Certified to EN-60950-1, 1st Edition
