FN406B-1-02

Power Line Filter 0Hz to 400Hz 1A 250VAC PC Pins Thru-Hole

General-purpose filters for PCB mounted applications offer high performance in an exceptionally compact form, ideal for applications where space is at a premium. Supplied in an aluminum housing that provides excellent RF shielding to protect against coupling effects from nearby components. With a footprint of just 15 × 45 mm, it greatly reduces the PCB area required, compared with using discrete components. It has a height profile which does not exceed the capacitors and transformers typically used in circuitry such as switched mode power supplies.

* 250 VAC Maximum Operating Voltage at 50/60 Hz

* DC to 400 Hz Operating Frequency

* 190 μA Leakage Current

* Thru-Hole PCB Mounting

* Aluminum Case

* 36 Gm Weight

* 1,900,000 Hours MTBF at 40°C, 230 V, Per Mil-HB-217F
