PMODTPH

DIGILENT PMODTPH Pmod 6Pin Test Point Header

Test Point Header module board the TPH is an ideal way to test the connection between a Pmod and system board. It simply passes signals from the J1 connector to the J2 connector, providing test point access via the J2 header. The TPH allows for testing and debugging individual connections using an oscilloscope, voltmeter, or logic analyzer.

.

Two 6 pin pass through headers

.

A 6 pin test point header

.

Small form factor 1.00inch x 0.80inch
