STC-DRS-232

Surge Suppressor; Data/Comm; 10kA; 52V; 60VBrkdn; DIN Rail Mnt; Screw Term; STC-DRS

Sola"s STC-DRS Series is a DIN rail mountable, single pair surge suppression module implementing three-stage hybrid technology. This module addresses over-voltage transients with gas tubes and silicon avalanche components. In addition, sneak currents are mitigated with resettable fuses PTCs. The PTC increases resistance by several orders of magnitude when over currents exceed safe levels. A normal state resumes when over currents are removed. The ability to self-restore in this manner significantly increases suppressor performance and survivability. The STC-DRS Series mounts onto a standard 35 mm industrial DIN rail. There are three Field Side and three Electronics Side screw terminals. One is reserved for a shield. Three electronically tied ground terminals are provided for grounding the unit to building-approved ground. The shield is isolated from ground.

**Features:**

* Low-Voltage Data Surge Protection

* Three-Stage Hybrid Protection

* Sneak/Fault Current Protection with Resettable Fuses PTCs

* Low Profile Packaging

* Easy Installation — Only 6 Screw Terminals

* Fits Standard 35 mm DIN Rail

* Fast Response Time <1 Nanosecond

* Typical Capacitance: 1500 pF

* UL 497B Listed

* Five-Year Warranty
