CXSM6-30

SMC CXS 双杆气缸幅度SMC 双杆气缸，带滑动轴承（CXSM 型）或滚珠轴承滑轨（CXSL 类型），适用于“即取即装”应用，操作非润滑、过滤、压缩空气。 双杆气缸具有高非旋转精度、双端口位置、标准磁性感应和缓冲器缓冲。 可整体调整冲程标准，减少 5 mm。 气缸包含用于自动开关的凹槽，可在 5 至 60°C 的工作环境中使用。### SMC CX2N/CXSM/CSXL 双杆气缸

CXS slide units are intended to replace a custom assembly consisting of many components with one integrated and reliable component. CX offers excellent value when the accuracy and moment capabilities of the MX slide are not required. The CX has very good non-rotating accuracy and intermediate to high loading capabilities. The twin piston design provides twice the thrust for a given bore size. Dual-Rod Cylinder with guide function for pick-and-place applications. Series CXS is compact and has accurate non-rotating specification.

**Features:**

* Dual Piston Design Which Provides Twice the Thrust of Conventional Actuators

* Non-Rotating Accuracy: ±0.1°, Perfect for the Majority of Automation Requirements

* Slide Bearings Are Standard

* Standard Stroke Retraction Adjusters

* Adjustable Stroke Range: 0 to 5 mm

* 3-Side Work Piece Mounting

* Operating Pressure: 14.5-101.5 psi 10-15 mm Bore, 7.2-101.5 psi 20-25 mm Bore
