STN2907AS

STN2907AS PNP三极管 -60V -600mA/- 0.6A 250MHz 75 -400mV/-0.4V SOT-23/SC-59 marking/标记 WA 低集电极饱和电压/开关

集电极-基极反向击穿电压VBRCBOCollector-Base VoltageVCBO| -60V \---|--- 集电极-发射极反向击穿电压VBRCEOCollector-Emitter VoltageVCEO| −50V 集电极连续输出电流ICCollector CurrentIC| −600mA/- 0.6A 截止频率fTTranstion FrequencyfT| 250MHz 直流电流增益hFEDC Current GainhFE| 75 管压降VCE（sat）Collector-Emitter SaturationVoltage| -400mV/-0.4V 耗散功率PcPoWer Dissipation| 350mW/0.35W Description & Applications| PNP Silicon Transistor Descriptions • General purpose application • Switching application Features • Large collector current • Low collector saturation voltage • Complementary pair with STN2222AS 描述与应用| PNP硅晶体管 简述 •通用应用 •开关应用 特点 •大集电极电流 •低集电极饱和电压 •STN2222AS互补配对
