CD74HCT4094EE4
TI(德州仪器)
主动器件
高速CMOS逻辑8级移位和存储总线寄存器，三态 HIgh-Speed CMOS Logic 8-Stage Shift and Store Bus Register,Three-State
Description
The ’HC4094 and CD74HCT4094 are 8-stage serial shift registers having a storage latch associated with each stage for strobing data from the serial input to parallel buffered three-state outputs. The parallel outputs may be connected directly to common bus lines. Data is shifted on positive
clock transitions. The data in each shift register stage is transferred to the storage register when the Strobe input is high. Data in the storage register appears at the outputs whenever the Output-Enable signal is high.
