CD74AC20E
TI(德州仪器)
主动器件
TEXAS INSTRUMENTS CD74AC20E 与非门, AC系列, 4输入, 24 mA, 1.5V至5.5V, DIP-14
The is a dual 4-input NAND Gate. This device performs the Boolean function Y = A • B • C • D\ or Y = A\ + B\ + C\ + D\ in positive logic. The device features 1.5 to 5.5V operation and balanced noise immunity at 30% of the supply voltage.
- .
- ±24mA Output drive current
- .
- Speed of bipolar F, AS and S with significantly reduced power consumption
- .
- Exceeds 2kV ESD protection per MIL-STD-883, method 3015
- .
- SCR-latchup-resistant CMOS process and circuit design
