ADS5545IRGZ25

14Bit 170MSPS ADC with LVDS/CMOS Outputs 48-VQFN -40℃ to 85℃

14 Bit Analog to Digital Converter 1 Input 1 48-VQFN 7x7

得捷:
IC ADC 14BIT PIPELINED 48VQFN

贸泽:
Analog to Digital Converters - ADC 14B 170MSPS ADC

艾睿:
Single Channel Single ADC Pipelined 170Msps 14-bit Parallel/Serial/LVDS 48-Pin VQFN EP T/R

安富利:
ADS5545 is a high performance 14-bit, 170-MSPS A/D converter. It offers state-of-the-art functionality and performance using advanced techniques to minimize board space. Using an internal sample and hold and low jitter clock buffer, the ADC supports both high SNR and high SFDR at high input frequencies. It features programmable gain options that can be used to improve SFDR performance at lower full-scale analog input ranges.In a compact 48-pin QFN, the device offers fully differential LVDS DDR Double Data Rate interface while parallel CMOS outputs can also be selected. Flexible output clock position programmability is available to ease capture and trade-off setup for hold times. At lower sampling rates, the ADC can be operated at scaled down power with no loss in performance. ADS5545 includes an internal reference, while eliminating the traditional reference pins and associated external decoupling. The device also supports an external reference mode. The device is specified over the industrial temperature range -40°C to 85°C.
