SN74AHC125NE4
TI(德州仪器)
电子元器件分类
具有三态输出翻两番总线缓冲器GATES QUADRUPLE BUS BUFFER GATES WITH 3-STATE OUTPUTS
DESCRIPON
The ’AHC125 devices are quadruple bus buffer gates featuring independent line drivers with 3-state outputs. Each output is disabled when the associated output-enable OE input is high. When OE is low, the respective gate passes the data from the A input to its Y output.
Operating Range 2-V to 5.5-V VCC
Latch-Up Performance Exceeds 250 mA Per JESD 17
得捷:
4-CH, 2-V TO 5.5-V BUFFERS WITH
艾睿:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin PDIP Tube
Chip1Stop:
Buffer/Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin PDIP Tube
德州仪器TI:
4-ch, 2-V to 5.5-V buffers with 3-state outputs
