MC33030PG

直流伺服电机控制器/驱动器

DC Servo Motor Controller/Driver

The MC33030 is a monolithic DC servo motor controller providing all active functions necessary for a complete closed loop system. This device consists of an on−chip op amp and window comparator with wide input common−mode range, drive and brake logic with direction memory, Power H−Switch driver capable of 1.0 A, independently programmable overcurrent monitor and shutdown delay, and overvoltage monitor. This part is ideally suited for almost any servo positioning application that requires sensing of temperature, pressure, light, magnetic flux, or any other means that can be converted to a voltage.

Features

•On−Chip Error Amp for Feedback Monitoring

•Window Detector with Deadband and Self Centering Reference Input

•Drive/Brake Logic with Direction Memory

•1.0 A Power H−Switch

•Programmable Overcurrent Detector

•Programmable Overcurrent Shutdown Delay

•Overvoltage Shutdown

•Pb−Free Packages are Available

.
