MC100EPT26DTR2

1 ： 2扇出差分LVPECL到LVTTL翻译 1:2 Fanout Differential LVPECL to LVTTL Translator

Description

The MC100EPT26 is a 1:2 Fanout Differential LVPECL/LVDS to LVTTL translator. Because LVPECL Positive ECL or LVDS levels are used only +3.3 V and ground are required. The small outline 8−lead package and the 1:2 fanout design of the EPT26 makes it ideal for applications which require the low skew duplication of a signal in a tightly packed PC board.

Features

• 1.4 ns Typical Propagation Delay

• Maximum Frequency > 275 MHz Typical

• The 100 Series Contains Temperature Compensation

• Operating Range: VCC = 3.0 V to 3.6 V with GND = 0 V

• 24 mA TTL outputs

• Q Outputs Will Default LOW with Inputs Open or at VEE

• VBB Output

• Pb−Free Packages are Available
