TLV70712PDQNR

200毫安，低IQ ，低噪声，低压差稳压器用于便携式设备 200-mA, Low-IQ, Low-Noise, Low-Dropout Regulator for Portable Devices

PMIC - 稳压器 - 线性 正 固定 输出 200mA 4-X2SON（1x1）

得捷:
IC REG LINEAR 1.2V 200MA 4X2SON

立创商城:
正 Vin=5.5V Vout=1.2V~1.2V 200mA 70dB

德州仪器TI:
200-mA, low-IQ, low-dropout voltage regulator with enable & active output discharge

贸泽:
LDO Voltage Regulators 200mA,Low-IQ,Low- Noise,LDO Reg

艾睿:
Having trouble maintaining a steady voltage? This LDO TLV70712PDQNR linear regulator from Texas Instruments will give you control over the voltage levels of your circuit. Its typical dropout voltage at current is 0.25@150mA V. This device has a maximum power dissipation of 400 mW. It has an overall accuracy of ±0.5Typ %. This voltage regulation device&s;s single output can produce a current up to 0.2 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2 V and no higher than 5.5 V. With a fixed output that has a voltage of 1.2 V, this is power management at its best. Using a load regulation of 10mVTyp and line regulation of 1mVTyp is needed for a programmable DC power supply. Its maximum power dissipation is 400 mW. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 85 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 1.2V 0.2A 4-Pin X2SON T/R

Chip1Stop:
LDO Regulator Pos 1.2V 0.2A 4-Pin X2SON EP T/R

Verical:
LDO Regulator Pos 1.2V 0.2A 4-Pin X2SON EP T/R
