TLV5629IDW
8通道， 12位/ 10位/ 8位， 2.7 V至5.5 V低功耗 8-CHANNEL, 12-/10-/8-BIT, 2.7-V TO 5.5-V LOW POWER
DESCRIPON
The TLV5610, TLV5608, and TLV5629 are pin-compatible, eight-channel, 12-/10-/8-bit voltage output DACs each with a flexible serial interface. The serial interface allows glueless interface to TMS320 and SPI, QSPI, and Microwire serial ports. It is programmed with a 16-bit serial string containing 4 control and 12 data bits.
FEATURES
• Eight Voltage Output DACs in One Package
– TLV5610 . . . 12-Bit
– TLV5608 . . . 10-Bit
– TLV5629 . . . 8-Bit
• Programmable Settling Time vs Power Consumption
– 1 µs In Fast Mode
– 3 µs In Slow Mode
• Compatible With TMS320 and SPI™ Serial Ports
• Monotonic Over Temperature
• Low Power Consumption:
– 18 mW In Slow Mode at 3-V
– 48 mW In Fast Mode at 3-V
• Reference Input Buffers
• Power-Down Mode
• Buffered, High Impedance Reference Inputs
• Data Output for Daisy-Chaining
APPLICATIONS
• Digital Servo Control Loops
• Digital Offset and Gain Adjustment
• Industrial Process Control
• Machine and Motion Control Devices
• Mass Storage Devices
