TLC5628IDWR
8 位，10us 八路 DAC，串行输入，1x 或 2x 输出可编程，同步更新，低功耗 16-SOIC -40 to 85
description
The TLC5628C and TLC5628I are octal 8-bit voltage output digital-to-analog converters DACs with buffered reference inputs high impedance. The DACs produce an output voltage that ranges between either one or two times the reference voltages and GND and are monotonic. The device is simple to use, running from a single supply of 5 V. A power-on reset function is incorporated to ensure repeatable start-up conditions.
Eight 8-Bit Voltage Output DACs
5-V Single-Supply Operation
Serial Interface
High-Impedance Reference Inputs
Programmable 1 or 2 Times Output Range
Simultaneous Update Facility
Internal Power-On Reset
Low-Power Consumption
Half-Buffered Output
applications
Programmable Voltage Sources
Digitally Controlled Amplifiers/Attenuators
Mobile Communications
Automatic Test Equipment
Process Monitoring and Control
Signal Synthesis
