SN74LVC1G14DRLR
TI(德州仪器)
主动器件
TEXAS INSTRUMENTS SN74LVC1G14DRLR 非门, LVC系列, 施密特触发, 1输入, 5 ns, 1.65V至5.5V, SOT-553-5
The is a single Schmitt-trigger Inverter. The device performs the Boolean function Y = A\\. The device functions as an independent inverter, but because of Schmitt action, it may have different input threshold levels for positive-going VT+ and negative-going VT- signals. This device is fully specified for partial-power-down applications using Ioff. The Ioff circuitry disables the outputs, preventing damaging current backflow through the device when it is powered down.
- .
- ±24mA Output drive at 3.3V
- .
- 10µA Maximum ICC low power consumption
- .
- Inputs accept voltages to 5.5V
- .
- Maximum tpd of 4.6ns at 3.3V
- .
- Ioff supports partial-power-down mode operation
- .
- ESD protection exceeds JESD 22
- .
- Latch-up performance exceeds 100mA per JESD 78, Class II
