UCC38085D

8引脚的电流模式推挽PWM具有可编程斜率补偿CONTROLLERS 8-PIN CURRENT MODE PUSH-PULL PWM CONTROLLERS WITH PROGRAMMABLE SLOPE COMPENSATION

离线转换器 推挽式 拓扑 50kHz ~ 1MHz 8-SOIC

得捷:
IC OFFLINE SW PUSH-PULL 8SOIC

立创商城:
UCC38085D

德州仪器TI:
Current mode push-pull PWM with prog. slope comp, 100µs soft start, 12.5/8.3 UVLO, 0°C to 70°C

贸泽:
开关控制器 Crnt Mode Push-Pull w/Prog Slope Comp

艾睿:
This UCC38085D current controller by Texas Instruments will exceed your current supply needs. This current mode controller supports boost|buck|half-bridge|push-pull topology. Its 2 PWM outputs produce a current of 1000Max mA. You can operate this at a switching frequency of 50 to 1000 kHz. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This current mode controller&s;s maximum duty cycle is 50 %. This device has a maximum of 15 V. This current mode controller has a minimum operating temperature of 0 °C and a maximum of 70 °C.

安富利:
Current Mode PWM Controller 1A 8-Pin SOIC Tube

Chip1Stop:
Current Mode PWM Controller 1A 8-Pin SOIC Tube

Verical:
Current Mode PWM Controller 1A 50kHz to 1000kHz 8-Pin SOIC Tube
