UC3524DW
高级稳压脉宽调制器 Advanced Regulating Pulse Width Modulators
Messages can be encoded with pulsating voltages by using this voltage mode PWM controller from Texas Instruments. Its 2 PWM outputs produce a current of 100Max mA. This voltage mode driver supports boost|flyback|forward|full-bridge|half-bridge|push-pull topology. It has a switching frequency of 300Typ kHz. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This voltage mode driver has a minimum operating temperature of 0 °C and a maximum of 70 °C. This device has a minimum operating supply voltage of 8 V and a maximum of 40 V. This voltage mode driver"s maximum duty cycle is 45 %.
