UCC3813D-0
TI(德州仪器)
音频放大器
TEXAS INSTRUMENTS UCC3813D-0 控制器, 电流模式控制器, PWM, 12V-0V电源, 1 MHz, 1V/1A输出, SOIC-8
The is a low-power BiCMOS current-mode Pulse Width Modulation PWM Controller contains all of the control and drive components required for off-line and DC to DC fixed-frequency current-mode switching power supplies with minimal parts count. It has the same pin configuration as the UC384x family and also offers the added features of internal full-cycle soft start and internal leading-edge blanking of the current-sense input.
- .
- Internal soft start
- .
- Internal fault soft start
- .
- Internal leading-edge blanking of the current-sense signal
- .
- 1A Totem-pole output
- .
- 70ns Typical response from current-sense to gate-drive output
- .
- 1.5% Tolerance voltage reference
- .
- Green product and no Sb/Br
