UA741CPE4
TI(德州仪器)
主动器件
TEXAS INSTRUMENTS UA741CPE4 运算放大器, 单路, 1 MHz, 1个放大器, 0.5 V/µs, ± 9V 至 ± 15V, DIP, 8 引脚
The is a general-purpose Operational Amplifier features offset-voltage null capability. The high common-mode input voltage range and the absence of latch-up make the amplifier ideal for voltage-follower applications. The device is short-circuit protected and the internal frequency compensation ensures stability without external components. A low value potentiometer may be connected between the offset null inputs to null out the offset voltage as shown in.
- .
- Short-circuit protection
- .
- Offset-voltage null capability
- .
- Large common-mode and differential voltage ranges
- .
- No frequency compensation required
- .
- No latch-up
ESD sensitive device, take proper precaution while handling the device.
