TPS2223APWPR

CARDBUS电接口开关，用于串行PCMCIA CONTROLLERS CARDBUS POWER-INTERFACE SWITCHES FOR SERIAL PCMCIA CONTROLLERS

Power Switch/Driver 3:4 1A 24-HTSSOP

得捷:
IC PWR SWITCH 3:4 24HTSSOP

立创商城:
TPS2223APWPR

德州仪器TI:
Dual-Slot Cardbus Power-Interface Switches for Serial PCMCIA Controllers

贸泽:
开关 IC - 各种 Dual-Slot Power Interface

艾睿:
Power Interface Switch 24-Pin HTSSOP EP T/R

安富利:
The TPS2223A, TPS2224A, and TPS2226A CardBus™ power-interface switches provide an integrated power-management solution for two PC Card sockets. The TPS2220A is a single-slot option for this family of devices. These devices allow the controlled distribution of 3.3 V, 5 V, and 12 V to each card slot. The current-limiting and thermal-protection features eliminate the need for fuses. Current-limit reporting helps the user isolate a system fault. The switch rDSon and current-limit values have been set for the peak and average current requirements stated in the PC Card specification, and optimized for cost. A faster maximum current limit response time is the only difference between the TPS2223A, TPS2224A, and TPS2226A and the TPS2223, TPS2224, and TPS2226.Like the TPS2214 and TPS2214A and the TPS2216 and TPS2216A, this family of devices supports independent VPP/VCC switching; however, the standby and interface-mode pins are not supported. Shutdown mode is now supported independently on SHDN\ as well as in the serial interface. Optimized for lower power implementation, the TPS2223A does not support 12-V switching to VPP.

Verical:
Current Limit SW 1-IN 1-OUT 7V to 13.5V 1A 24-Pin HTSSOP EP T/R

Win Source:
IC PWR INTRFACE SWITCH 24-HTSSOP
