TPS2561ADRCT

双通道精密可调电流限制电源开关 Dual Channel Precision Adjustable Current-Limited Power Switches

DESCRIPON

The TPS2560A and TPS2561A are dual-channel power-distribution switches intended for applications where precision current limiting is required or heavy capacitive loads and short circuits are encountered. These devices offer a programmable current-limit threshold between 250 mA and 2.8 A typ per channel via an external resistor. The power-switch rise and fall times are controlled to minimize current surges during turn on/off.

FEATURES

• Two separate current limiting channels

• Meets USB Current-Limiting Requirements

• Adjustable Current Limit, 250 mA–2.8 A typ

• Accurate 2.1A Min / 2.5A Max SettingIncluding Resistor

• Fast Overcurrent Response - 3.5-μs typ

• Two 44-mΩ High-Side MOSFETs

• Operating Range: 2.5 V to 6.5 V

• 2-μA Maximum Standby Supply Current

• Built-in Soft-Start

• 15 kV / 8 kV System-Level ESD Capable

• UL Listed – File No. E169910

• CB & Nemko Certified
