TPS71247DRCR

具有使能功能的 250mA、双通道低压降稳压器 10-VSON -40 to 125

Stable voltages are always needed for sensitive systems implement this LDO linear regulator from Texas Instruments. It has an overall accuracy of ±1.5 %. Its typical dropout voltage at current is 0.125@250mA V. This device has a maximum power dissipation of 1920 mW. This voltage regulation device"s 2 outputs can produce a current up to 0.25 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.7 V that does not exceed 5.5 V. With a fixed output that has a voltage of 1.8|2.85 V, this is power management at its best. By operating at a load regulation of 0.8%/mATyp and line regulation of 0.05%/VTyp you can provide a constant voltage at your output. Its maximum power dissipation is 1920 mW. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. Its polarity is positive. The maximum dropout voltage is 0.23@250mA V. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.
