TPS73725DCQ
1A低压降稳压器具有反向电流保护 1A Low-Dropout Regulator with Reverse Current Protection
PMIC - 稳压器 - 线性 正 固定 输出 1A SOT-223-6
立创商城:
TPS73725DCQ
德州仪器TI:
1-A, ultra-low-dropout voltage regulator with reverse current protection & enable
得捷:
IC REG LINEAR 2.5V 1A SOT223-6
艾睿:
This LDO TPS73725DCQ linear regulator from Texas Instruments is used to manipulate the voltage level of your circuit. It has an overall accuracy of ±1 %. Its typical dropout voltage at current is 0.13@1A V. This voltage regulation device&s;s single output can produce a current up to 1 A. With a small input voltage of 2.2 V and a max of 5.5 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 2.5 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 0.002%/mATyp and line regulation of 0.01%/VTyp. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. The maximum dropout voltage is 0.5@1A V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.
安富利:
LDO Regulator Pos 2.5V 1A 6-Pin5+Tab SOT-223 Tube
Chip1Stop:
Single Channel LDO Single Output LDO, 1A, Fixed 2.5V, Reverse Current Protection LDO Regulator Pos 2.5V 1A 6-Pin5+Tab SOT-223 Tube
TME:
Voltage regulator; LDO, fixed; 2.5V; 1A; SOT223-6; SMD; Channels:1
Verical:
LDO Regulator Pos 2.5V 1A 6-Pin5+Tab SOT-223 Tube
Newark:
# TEXAS INSTRUMENTS TPS73725DCQ Fixed LDO Voltage Regulator, 2.2V to 5.5V, 130mV Dropout, 2.5Vout, 1Aout, SOT-223-6
Win Source:
IC REG LDO 2.5V 1A SOT223-6
