TPS72215DBVT
LDO（低压降）线性稳压器，最大 100mA，1.0V 至 2.9V，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
LDO（低压降）线性稳压器，最大 100mA，1.0V 至 2.9V，Texas Instruments
得捷:
IC REG LINEAR 1.5V 50MA SOT23-5
立创商城:
TPS72215DBVT
德州仪器TI:
50-mA, low-dropout voltage regulator with enable
欧时:
LDO（低压降）线性稳压器，最大 100mA，1.0V 至 2.9V，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
贸泽:
低压差稳压器 Low-Noise Low Input Voltage 50mA
艾睿:
Stable voltages are always needed for sensitive systems implement this LDO TPS72215DBVT linear regulator from Texas Instruments. This device has a maximum power dissipation of 555 mW. Its typical dropout voltage at current is 0.05@50mA V. It has an overall accuracy of ±3 %. This voltage regulation device&s;s single output can produce a current up to 0.05 A. The best way to provide power to your application is by using this, which needs a voltage of at least 1.8 V and no higher than 5.5 V. With a fixed output that has a voltage of 1.5 V, this is power management at its best. Using a load regulation of 0.2mVTyp and line regulation of 0.09%/V is needed for a programmable DC power supply. Its maximum power dissipation is 555 mW. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive.
安富利:
LDO Regulator Pos 1.5V 0.05A 5-Pin SOT-23 T/R
Chip1Stop:
Single Channel LDO Single Output LDO, 50mA, Fixed1.5V, Cap Free, Low Noise, Low Input Voltage LDO Regulator Pos 1.5V 0.05A 5-Pin SOT-23 T/R
Verical:
LDO Regulator Pos 1.5V 0.05A 5-Pin SOT-23 T/R
Newark:
# TEXAS INSTRUMENTS TPS72215DBVT Fixed LDO Voltage Regulator, 1.8V to 5.5V, 50mV Dropout, 1.5Vout, 50mAout, SOT-23-5
Win Source:
IC REG LDO 1.5V 50MA SOT23-5
