TLV7163030PDPQR

电容 - 免费，双通道， 150毫安，低压差稳压器（ LDO ）的1,2-毫米1,2毫米SON封装 Capacitor-Free, Dual, 150-mA, Low-Dropout Voltage Regulator LDO in 1,2-mm 1,2-mm SON Package

PMIC - 稳压器 - 线性 正 固定 2 输出 150mA 6-X2SON（1.2x1.2）

立创商城:
TLV7163030PDPQR

德州仪器TI:
150-mA, dual-channel low-dropout voltage regulator with enable

得捷:
IC REG LDO DUAL 3V 0.15A 6-SON

艾睿:
Don&s;t let unpredictable voltage levels ruin your circuit! Use this LDO TLV7163030PDPQR linear regulator from Texas Instruments to control your voltage levels! It has an overall accuracy of ±1 %. Its typical dropout voltage at current is 0.21@150mA V. This voltage regulation device&s;s 2 outputs can produce a current up to 0.15Min|0.15Min A. The best way to provide power to your application is by using this, which needs a voltage of at least 1.4 V and no higher than 5.5 V. With a fixed output that has a voltage of 3|3 V, this is power management at its best. Users like the load regulation of 0.07mV/mATyp and line regulation of 0.02%/VTyp. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive. The maximum dropout voltage is 0.42@150mA V.

安富利:
LDO Regulator Pos 3V/3V 0.15A 6-Pin X2SON T/R

Verical:
LDO Regulator Pos 3V3V 0.15A/0.15A 6-Pin X2SON EP T/R
