TSW-102-06-F-S

2.54mm 方针

针座 通孔 2 位置 0.100"（2.54mm）

欧时:
HEADER TH 2POS 2.54MM 1 ROW

立创商城:
2.54mm 方针

得捷:
CONN HEADER VERT 2POS 2.54MM

艾睿:
Samtec&s;s unshrouded TSW-102-06-F-S header connector is a great way to reduce safety concerns in projects where there is a possibility of accidentally shorting electronic components. This HDR connector&s;s 2 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a maximum voltage rating of 550 VAC. This is a 1-row connector. It has a header type gender. It has a straight body orientation. Its pitch is 2.54 mm. This device has a maximum current rating of 6.3 A/contact. This product is 5.08 mm long, 5.21 mm tall and 2.54 mm deep. TSW-102-06-F-S is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method.

安富利:
Conn Unshrouded Header HDR 2 POS 2.54mm Solder ST Thru-Hole

Newark:
# SAMTEC  TSW-102-06-F-S  Board-To-Board Connector, 2.54 mm, 2 Contacts, Header, TSW Series, Through Hole, 1 Rows
