THS4271DGK
低噪声，高转换速率，单位增益稳定的电压放大器客户反馈 LOW NOISE, HIGH SLEW RATE, UNITY GAIN STABLE VOLTAGE FREEBACK AMPLIFIER
DESCRIPON
The THS4271 and THS4275 are low-noise, high slew rate, unity gain stable voltage-feedback amplifiers designed to run from supply voltages as low as 5 V and as high as ±5 V. The THS4275 offers the same performance as the THS4271 with the addition of a power-down capability. The combination of low-noise, high slew rate, wide bandwidth, low distortion, and unity gain stability make the THS4271 and THS4275 high performance devices across multiple ac specifications.
FEATURES
• Unity Gain Stability
• Low Voltage Noise
– 3 nV/√Hz
• High Slew Rate: 1000 V/μs
• Low Distortion
– –92 dBc THD at 30 MHz
• Wide Bandwidth: 1.4 GHz
• Supply Voltages
– +5 V, ±5 V
• Power Down Functionality THS4275
• Evaluation Module Available
APPLICATIONS
• High Linearity ADC Preamplifier
• Wireless Communication Receivers
• Differential to Single-Ended Conversion
• DAC Output Buffer
• Active Filtering
