SN74F377ADWR
TI(德州仪器)
主动器件
具有时钟使能端的八路 D 型触发器 20-SOIC 0 to 70
The SN74F377A is a monolithic, positive-edge-triggered, octal, D-type flip-flop with clock enable inputs. The SN74F377A features a latched clock enable input.
Information at the data D inputs meeting the setup time requirements is transferred to the Q outputs on the positive-going edge of the clock pulse if is low. Clock triggering occurs at a particular voltage level and is not directly related to the positive-going pulse. When the clock input is at either the high or low level, the D input signal has no effect at the output. The circuits are designed to prevent false clocking by transitions at the input.
The SN74F377A is characterized for operation from 0°C to 70°C.
