SN74LVC2G74DCUR
TEXAS INSTRUMENTS SN74LVC2G74DCUR 触发器, 差分 /互补输出, 正沿, D, 4.1 ns, 200 MHz, 32 mA, VSSOP, 8 引脚
The is a single Positive-edge-triggered D-type Flip-flop with clear and preset. A low level at the preset PRE or clear CLR input sets or resets the outputs, regardless of the levels of the other inputs. When PRE and CLR are inactive high, data at the data D input meeting the setup time requirements is transferred to the outputs on the positive-going edge of the clock pulse. Clock triggering occurs at a voltage level and is not related directly to the rise time of the clock pulse. Following the hold-time interval, data at the D-input can be changed without affecting the levels at the outputs.
- .
- 5.9ns at 3.3V Maximum TPD
- .
- Low power consumption
- .
- IOFF supports live insertion, partial-power-down mode and back-drive protection
- .
- Latch-up performance exceeds 100mA per JESD 78
- .
- ESD protection exceeds JESD 22
This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
