SN74ACT14DBR
TI(德州仪器)
主动器件
六角施密特触发器逆变器 HEX SCHMITT-TRIGGER INVERTER
description/ordering information
These Schmitt-trigger devices contain six independent inverters. They perform the Boolean function Y = A. Because of the Schmitt action, they have different input threshold levels for positive-going VT+ and for negative-going VT− signals.
These circuits are temperature compensated and can be triggered from the slowest of input ramps and still give clean, jitter-free output signals. They also have a greater noise margin than conventional inverters.
• 4.5-V to 5.5-V VCC Operation
• Inputs Accept Voltages to 5.5 V
• Max tpd of 11 ns at 5 V
• Inputs Are TTL-Voltage Compatible
