SN74AHCT86RGYR
TI(德州仪器)
主动器件
四路2输入异或门 QUADRUPLE 2-INPUT EXCLUSIVE-OR GATES
Description
The SNx4AHCT86 devices are quadruple 2-input exclusive-OR gates. These devices perform the Boolean function Y = A × B or Y = AB + AB in positive logic.
Features
• Inputs are TTL-Voltage Compatible
• Latch-Up Performance Exceeds 250 mA Per JESD 17
• On Products Compliant to MIL-PRF-38535, All Parameters are Tested Unless Otherwise Noted. On All Other Products, Production Processing Does Not Necessarily Include Testing of All Parameters.
• ESD Protection Exceeds JESD 22
– 2000-V Human-Body Model A114-A
– 200-V Machine Model A115-A
Applications
• Server
• PCs and Notebooks
• Network Switches
• Wearable Health and Fitness Devices
• Telecom Infrastructures
• Electronic Points of Sale
