SN65C1168PWG4
TI(德州仪器)
电子元器件分类
双路差动驱动器和接收 DUAL DIFFERENTIAL DRIVERS AND RECEIVERS
The SN65C1167, SN75C1167, SN65C1168, and SN75C1168 dual drivers and receivers are integrated circuits designed for balanced transmission lines. The devices meet A/EIA-422-B and ITU recommendation V.11.
Meet or Exceed Standards TIA/EIA-422-B and ITU Recommendation V.11
BiCMOS Process Technology
Low Supply-Current Requirements: 9 mA Max
Low Pulse Skew
Receiver Input Impedance...17 kΩTyp
Receiver Input Sensitivity...±200 mV
Receiver Common-Mode Input Voltage Range of −7 V to 7 V
Operate From Single 5-V Power Supply
Glitch-Free Power-Up/Power-Down Protection
Receiver 3-State Outputs Active-Low Enable for SN65C1167 and SN75C1167 Only
Improved Replacements for the MC34050 and MC34051
