SN74LV4051ADGVR

8通道模拟多路复用器/多路解复用器 8-CHANNEL ANALOG MULTIPLEXERS/DEMULTIPLEXERS

description/ordering information

These 8-channel CMOS analog multiplexers/ demultiplexers are designed for 2-V to 5.5-V VCC

operation. The ’LV4051A devices handle both analog and digital signals. Each channel permits signals with amplitudes up to 5.5 V peak to be transmitted in either direction. Applications include signal gating, chopping, modulation or demodulation modem, and signal multiplexing for analog-to-digital and digital to analog conversion systems.

2-V to 5.5-V VCC Operation

Support Mixed-Mode Voltage Operation on All Ports

High On-Off Output-Voltage Ratio

Low Crosstalk Between Switches

Individual Switch Controls

Extremely Low Input Current

Latch-Up Performance Exceeds 100 mA Per JESD 78, Class II

ESD Protection Exceeds JESD 22

  − 2000-V Human-Body Model A114-A

  − 200-V Machine Model A115-A

  − 1000-V Charged-Device Model C101
