SN74ACT245NSR

八路总线收发器与3态输出 OCTAL BUS TRANSCEIVERS WITH 3-STATE OUTPUTS

Transceiver, Non-Inverting 1 Element 8 Bit per Element 3-State Output 20-SO

得捷:
IC TXRX NON-INVERT 5.5V 20SO

立创商城:
SN74ACT245NSR

德州仪器TI:
Octal Bus Transceivers With 3-State Outputs

贸泽:
总线收发器 Octal Bus Trnscvrs With 3-State Outputs

艾睿:
Bus XCVR Single 8-CH 3-ST 20-Pin SOP T/R

安富利:
These octal bus transceivers are designed for asynchronous two-way communication between data buses. The control-function implementation minimizes external timing requirements.When the output-enable OE is low, the device passes noninverted data from the A bus to the B bus or from the B bus to the A bus, depending upon the logic level at the direction-control DIR input. A high on OE disables the device so that the buses are effectively isolated.To ensure the high-impedance state during power up or power down, OE should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.

Chip1Stop:
Bus XCVR Single 8-CH 3-ST 20-Pin SOP T/R

Verical:
Bus XCVR Single 8-CH 3-ST 20-Pin SOP T/R

Win Source:
IC BUS TRANSCEIVER 8BIT 20SO

DeviceMart:
IC BUS TRANSCEIVER 8BIT 20SOP
