SBAW56WT1G
数据手册.pdf二极管 小信号, 双共阳极, 70 V, 200 mA, 1.25 V, 6 ns, 500 mA
阵列 1 对共阳极 标准 200mA（DC） 表面贴装型 SC-70，SOT-323
得捷:
DIODE ARRAY GP 70V 200MA SC75
立创商城:
SBAW56WT1G
欧时:
ON Semiconductor, SBAW56WT1G
贸泽:
二极管 - 通用，功率，开关 SS COM ANODE DU SW
e络盟:
二极管 小信号, 双共阳极, 70 V, 200 mA, 1.25 V, 6 ns, 500 mA
艾睿:
If your circuit needs to adjust from an AC to DC voltage use a small signal switching diode SBAW56WT1G rectifier from ON Semiconductor. Its maximum power dissipation is 300 mW. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It is made in a dual common anode configuration. Its peak non-repetitive surge current is 0.5 A, while its maximum continuous forward current is 0.2 A. This rectifier has a minimum operating temperature of -55 °C and a maximum of 150 °C.
安富利:
Diode Small Signal Switching 70V 0.2A 3-Pin SC-70 T/R
Chip1Stop:
Diode Small Signal Switching 70V 0.2A Automotive 3-Pin SC-70 T/R
Verical:
Rectifier Diode Small Signal Switching 0.2A 6ns Automotive 3-Pin SC-70 T/R
Win Source:
DIODE ARRAY GP 70V 200MA SC75
