REG103FA-AKTTT
LDO（低压降）线性稳压器，300mA 至 800mA，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
可调 LDO（低压降）线性稳压器，300mA 至 800mA，Texas Instruments
### LDO（低压降）线性稳压器，Texas Instruments
低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。
得捷:
IC REG LINEAR POS ADJ DDPAK
立创商城:
REG103FA-AKTTT
德州仪器TI:
500-mA, 15-V, low-dropout voltage regulator with power good & enable
欧时:
Texas Instruments REG103FA-AKTTT LDO 稳压器, 可调输出, 1.295 → 5.5 V输出, 500mA最大输出
贸泽:
LDO Voltage Regulators DMOS 500mA LDO Reg
艾睿:
Don&s;t let unpredictable voltage levels ruin your circuit! Use this LDO REG103FA-AKTTT linear regulator from Texas Instruments to control your voltage levels! It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.003@10mA|0.115@500mA V. This voltage regulation device&s;s single output can produce a current up to 0.5 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.1 V and no higher than 15 V. With an adjustable output that has a voltage of 1.295 to 5.5 V, this is power management at its best. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This voltage regulation device has a minimum operating temperature of -55 °C and a maximum of 125 °C. The maximum dropout voltage is 0.025@10mA|0.2@500mA V. Its polarity is positive.
安富利:
LDO Regulator Pos 1.295V to 5.5V 0.5A 6-Pin5+Tab TO-263 T/R
Chip1Stop:
Single Channel LDO Single Output LDO, 500mA, Adj.1.295 to 5.5V, Low Noise, Fast Transient Response LDO Regulator Pos 1.295V to 5.5V 0.5A 6-Pin5+Tab TO-263 T/R
Verical:
LDO Regulator Pos 1.295V to 5.5V 0.5A 6-Pin5+Tab TO-263 T/R
