REF5030AIDG4
TI(德州仪器)
主动器件
TEXAS INSTRUMENTS REF5030AIDG4 电压基准, 精密, 低噪, 系列 - 固定, REF5030系列, 3V, SOIC-8
The is a low-noise, low-drift, very high precision Voltage Reference, capable of both sinking and sourcing and are very robust with regard to line and load changes. Excellent temperature drift 3ppm/°C achieved using proprietary design techniques. These features, combined with very low noise, make the REF5030AIDG4 family ideal for use in high-precision data acquisition systems.
- .
- 3ppm/°C Maximum high-grade low temperature drift
- .
- 0.05% maximum High-grade high accuracy
- .
- 3µVPP/V Low noise
- .
- 45ppm/1000-hour typical after 1000-hour excellent long-term stability
- .
- ±10mA High output current
- .
- Green product and no Sb/Br
IC can be damaged by ESD. We recommend that all ICs be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.
