PM54-470L-RC

BOURNS JW MILLER  PM54-470L-RC  功率电感, 47uH, 15%容差, SMD

**Features:

**

* Formerly J.W. Miller Model

* Small Diameter of Only 5.8 mm Maximum

* Profile of 4.8 mm**

Applications:

**

* Input/Output of DC/DC Converters

* Power Supplies for: Portable Communication Equipment, Camcorders, LCD TVs and Car Radios

立创商城:
47uH ±15% 720mA 370mΩ

得捷:
FIXED IND 47UH 720MA 370MOHM SMD

e络盟:
电感, 47uH, 720mA, 15%, 12MHZ

艾睿:
This power PM54-470L-RC surface mount inductor from Bourns is placed on the surface of a PCB during surface mount manufacturing processing. This SMD inductor has an operating temperature range of -40 °C to 125 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This SMD inductor has a maximum DC current of 720m A with a maximum resistance of 370m Ohm. It has an inductance of 47u H. This product is 4.8 mm tall with a diameter of 5.8 mm. It has a tolerance of 15%. Its test frequency is 1K Hz, while its minimum self-resonant frequency is 12M Hz. This device utilizes bobbin core technology.

Allied Electronics:
Pwr Inductor; Non-Shielded; 47 uH; 15%; 0.37 Ohm DCR

Chip1Stop:
Ind Power Bobbin Core 47uH 15% 1KHz 22Q-Factor Ferrite 720mA T/R

Verical:
Inductor Power Wirewound 47uH 15% 1KHz 22Q-Factor Ferrite 0.72A 0.37Ohm DCR T/R

Newark:
# BOURNS JW MILLER  PM54-470L-RC  Surface Mount Power Inductor, PM54 Series, 47 µH, 720 mA, 1 A, Unshielded, 0.37 ohm

MASTER:
Inductor Power Bobbin Core 47uH 15% 1KHz 22Q-Factor Ferrite 720mA 370mOhm DCR T/R

Electro Sonic:
Inductor Power Bobbin Core 47uH 15% 1KHz 22Q-Factor Ferrite 720mA 370mOhm DCR T/R

Win Source:
47μH Unshielded Wirewound Inductor 720mA 370 mOhm Nonstandard
