OPA2379AIDCNR
TI(德州仪器)
电子元器件分类
1.8V ， 2.9毫安， 90KHz的轨至轨输入/输出放大器合理 1.8V, 2.9mA, 90kHz, Rail-to-Rail I/O RATIONAL AMPLIFIERS
DESCRIPON
The OPA379 family of micropower, low-voltage operational amplifiers is designed for battery-powered
applications. These amplifiers operate on a supply voltage as low as 1.8V. High-performance, single-supply operation with rail-to-rail capability makes the OPA379 family useful for a wide range of applications.
FEATURES
LOW NOISE: 2.8µVPP
microPower: 5.5µA max
LOW OFFSET VOLTAGE: 1.5mV max
DC PRECISION:
− CMRR: 100dB
− PSRR: 2µV/V
− AOL: 120dB
WIDE SUPPLY VOLTAGE RANGE: 1.8V to 5.5V
microSize PACKAGES
APPLICATIONS
BATTERY-POWERED INSTRUMENTS
PORTABLE DEVICES
MEDICAL INSTRUMENTS
HANDHELD TEST EQUIPMENT
