OPA188AID
TI(德州仪器)
主动器件
TEXAS INSTRUMENTS OPA188AID 运算放大器, 单路, 2 MHz, 1个放大器, 0.8 V/µs, 4V 至 36V, SOIC, 8 引脚
The is a precision low noise Operational Amplifier with rail-to-rail output. The OPA188 operational amplifier uses proprietary auto-zeroing techniques to provide low offset voltage and near zero-drift over time and temperature. This miniature high-precision low-quiescent current amplifier offers high input impedance and rail-to-rail output swing within 15mV of the rails. The input common-mode range includes the negative rail.
- .
- Input includes negative rail
- .
- RFI filtered inputs
- .
- Excellent DC precision - 142dB PSRR and 146dB CMRR
- .
- 25µV Maximum low offset voltage
- .
- 0.03µV/°C Zero-drift
- .
- 8.8nV/√Hz Low noise
- .
- 0.1 to 10Hz noise of 0.25µVPP
- .
- 136dB Open-loop gain
- .
- 510µA Maximum quiescent current
- .
- Green product and no Sb/Br
