MAX3232CDBE4
TI(德州仪器)
电子元器件分类
TEXAS INSTRUMENTS MAX3232CDBE4 收发器, RS232, 2驱动器, 3V-5.5电源, SSOP-16
The is a RS-232 multichannel Line Driver/Receiver with ±15kV ESD protection terminal to terminal serial-port connection terminals, including GND. The device meets the requirements of A/EIA-232-F and provides the electrical interface between an asynchronous communication controller and the serial-port connector. The charge pump and four small external capacitors allow operation from a single 3 to 5.5V supply. The device operates at data signalling rate up to 250kbps and a maximum of 30V/µs driver output slew rate.
- .
- 300µA Typical low supply current
- .
- Green product and no Sb/Br
