M27C801-100F1
数据手册.pdfSTMICROELECTRONICS M27C801-100F1 芯片, EPROM CMOS 8MB
Description
The M27C801 is an 8 Mbit EPROM offered in the two ranges UV ultra violet erase and OTP one time programmable. It is ideally suited for applications where fast turn-around and pattern experimentation are important requirements and is organized as 1,048,576 by 8bits.
Features
■ 5 V ± 10% supply voltage in Read operation
■ Access time: 55 ns
■ low Power Consumption:
– Active current: 35 mA at 5 MHz
– Standby current: 100 µA
■ Programming voltage: 12.75 V ± 0.25 V
■ Programming time: 50 µs/word
■ Electronic signature
– Manufacturer code: 20h
– Device code: 42h
■ ECOPACK® packages available
