MC74VHC50DTR2G
数据手册.pdfON Semiconductor(安森美)
电子元器件分类
六缓冲器
The MC74VHC50 is an advanced high speed CMOS buffer fabricated with silicon gate CMOS technology. The internal circuit is composed of three stages, including a buffered output which provides high noise immunity and stable output. The inputs tolerate voltages up to 7 V, allowing the interface of 5 V systems to 3 V systems.
• High Speed: tPD = 3.8 ns Typ at VCC = 5 V
• Low Power Dissipation: ICC = 2 μA Max at TA = 25°C
• High Noise Immunity: VNIH = VNIL = 28% VCC
• Power Down Protection Provided on Inputs
• Balanced Propagation Delays
• Designed for 2 V to 5.5 V Operating Range
• Low Noise: VOLP = 0.8 V Max
• These Devices are Pb−Free and are RoHS Compliant
