LE33ABD
数据手册.pdf非常低压降稳压器与抑制 VERY LOW DROP VOLTAGE REGULATORS WITH INHIBIT
DESCRIPTION
The LE00 regulator series are very Low Drop regulators available in SO-8 and TO-92 packages and in a wide range of output voltages. The very Low Drop voltage 0.2V and the very low quiescent current make them particularly suitable for Low Noise Low Power applications and specially in battery powered systems.
■ VERY LOW DROPOUT VOLTAGE 0.2V TYP
■ VERY LOW QUIESCENT CURRENT TYP. 50 µA IN OFF MODE, 0.5 mA IN ON MODE, NO LOAD
■ OUTPUT CURRENT UP TO 100 mA
■ OUTPUT VOLTAGES OF 1.25; 1.5; 2.5; 3; 3.3; 3.5; 4; 4.5; 4.7; 5; 5.2; 5.5; 6; 8V
■ INTERNAL CURRENT AND THERMAL LIMIT
■ ONLY 2.2 µF FOR STABILITY
■ AVAILABLE IN ± 1% A OR ± 2% C SELECTION AT 25°C
■ SUPPLY VOLTAGE REJECTION: 80db TYP.
■ TEMPERATURE RANGE: -40 TO 125 °C
