LM2576HVS-12/NOPB

SIMPLE SWITCHER® 3A降压型稳压器 SIMPLE SWITCHER® 3A Step-Down Voltage Regulator

The is a SIMPLE SWITCHER® low component count Step-down Regulator provides all the active functions for a step-down buck switching regulator, capable of driving 3A load with excellent line and load regulation. This regulator is available in fixed output voltages of 12V version and requiring a minimum number of external components, this regulator is simple to use and include internal frequency compensation and a fixed-frequency oscillator. The LM2576 series offers a high-efficiency replacement for popular three-terminal linear regulators. It substantially reduces the size of the heat sink and in some cases no heat sink is required. A standard series of inductors optimized for use with the regulator are available from several different manufacturers. This feature greatly simplifies the design of switch-mode power supplies.

.

Requires only 4 external components

.

52kHz Fixed frequency internal oscillator

.

TTL shutdown capability, low power standby mode

.

High efficiency

.

Uses readily available standard inductors

.

Thermal shutdown and current limit protection

.

P+ Product enhancement tested

This device has limited built-in ESD protection, leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.
